React Native Game Development - A Salient Guide

React Native + Matter.js
Anurag Garg
Anurag GargSoftware Engineer
lines
Hire our Development experts.
npx react-native init GameApp
Hire our Development experts.
npm install matter-js react-native-game-engine --save
Hire our Development experts.
import React, {PureComponent} from 'react';
import {StatusBar, StyleSheet, View} from 'react-native';
import Entities from './src/entities';
import {GameEngine} from 'react-native-game-engine';

export default class App extends PureComponent {
  constructor(props) {
    super(props);
    this.state = {
      running: true,
    };
    this.gameEngine = null;
    console.disableYellowBox = true;
  }

  render() {
    return (
      <View style={styles.container}>
        <GameEngine
          ref={ref => {
            this.gameEngine = ref;
          }}
          style={styles.gameContainer}
          entities={Entities()}
          running={this.state.running}>
          <StatusBar hidden={true} />
        </GameEngine>
      </View>
    );
  }
}

const styles = StyleSheet.create({
  container: {
    flex: 1,
    backgroundColor: '#000',
  },
  gameContainer: {
    position: 'absolute',
    top: 0,
    bottom: 0,
    left: 0,
    right: 0,
  },
});
Hire our Development experts.
import Plane from '../components/Plane';
import Matter from 'matter-js';

Matter.Common.isElement = () => false; //-- Overriding this function because the original references HTMLElement

export default restart => {
  //-- Cleanup existing entities..
  if (restart) {
    Matter.Engine.clear(restart.physics.engine);
  }

  let engine = Matter.Engine.create({enableSleeping: false});
  let world = engine.world;
  world.gravity.y = 0.25;
  const boxSize = 50;

  return {
    physics: {engine: engine, world: world},
    Plane: Plane(
      world,
      'pink',
      {x: 220, y: 400},
      {height: boxSize, width: boxSize},
    ),
  };
};
Hire our Development experts.
import React from 'react';
import {Image} from 'react-native';
import {array, object, string} from 'prop-types';
import Matter from 'matter-js';

const airplane = require('../../assets/airplane.png');

const Plane = props => {
  const width = props.size[0];
  const height = props.size[1];
  const x = props.body.position.x - width / 2;
  const y = props.body.position.y - height / 2;
  return (
    <Image
      style={{
        position: 'absolute',
        left: x,
        top: y,
        width: width,
        height: height,
      }}
      resizeMode="stretch"
      source={airplane}
    />
  );
};

export default (world, color, pos, size) => {
  const initialPlane = Matter.Bodies.rectangle(
    pos.x,
    pos.y,
    size.width,
    size.height,
  );
  Matter.World.add(world, [initialPlane]);

  return {
    body: initialPlane,
    size: [size.width, size.height],
    color: color,
    renderer: <Plane />,
  };
};

Plane.propTypes = {
  size: array,
  body: object,
  color: string,
};
Hire our Development experts.
import Systems from './src/systems';
<GameEngine
 ref={(ref) => { this.gameEngine = ref; }}
 style={styles.gameContainer}
 running={this.state.running}
 systems={Systems}
 entities={this.entities}>
</GameEngine>
Hire our Development experts.
import Physics from './physics';
export default [Physics];
Hire our Development experts.
import Matter from 'matter-js';

const Physics = (entities, {time, dispatch}) => {
  let engine = entities.physics.engine;
  Matter.Engine.update(engine, time.delta);
  return entities;
};

export default Physics;
Hire our Development experts.
import Matter from 'matter-js';

const UpdatePlane = (entities, {touches, time}) => {
  const engine = entities.physics.engine;
  touches
    .filter(t => t.type === 'press')
    .forEach(t => {
      Matter.Body.setVelocity(entities.Plane.body, {
        x: entities.Plane.body.velocity.x,
        y: -3,
      });
    });
  Matter.Engine.update(engine, time.delta);
  return entities;
};

export default UpdatePlane;
Hire our Development experts.
import Physics from './physics';
import Plane from './plane';
export default [Physics, Plane];




Hire our Development experts.
import React from 'react';
import {View, Image} from 'react-native';
import {array, object, string} from 'prop-types';
import Matter from 'matter-js';

const water = require('../../assets/water.png');

const Floor = props => {
  const width = props.size[0];
  const height = props.size[1];
  const x = props.body.position.x - width / 2;
  const y = props.body.position.y - height / 2;
  return (
    <View
      style={[
        {
          position: 'absolute',
          left: x,
          top: y,
          width: width,
          height: height,
          backgroundColor: props.color || 'pink',
        },
      ]}>
      <Image
        style={{width: width, height: height}}
        source={water}
        resizeMode="stretch"
      />
    </View>
  );
};

export default (world, color, pos, size) => {
  const initialFloor = Matter.Bodies.rectangle(
    pos.x,
    pos.y,
    size.width,
    size.height,
    {isStatic: true, friction: 1},
  );
  Matter.World.add(world, [initialFloor]);

  return {
    body: initialFloor,
    size: [size.width, size.height],
    color: color,
    renderer: <Floor />,
  };
};

Floor.propTypes = {
  size: array,
  body: object,
  color: string,
};
Hire our Development experts.
import React from 'react';
import {View} from 'react-native';
import {array, object, string} from 'prop-types';
import Matter from 'matter-js';

const Ceiling = props => {
  const width = props.size[0];
  const height = props.size[1];
  const x = props.body.position.x - width / 2;
  const y = props.body.position.y - height / 2;
  return (
    <View
      style={[
        {
          position: 'absolute',
          left: x,
          top: y,
          width: width,
          height: height,
          backgroundColor: props.color || 'pink',
        },
      ]}
    />
  );
};

export default (world, color, pos, size) => {
  const initialCeiling = Matter.Bodies.rectangle(
    pos.x,
    pos.y,
    size.width,
    size.height,
    {isStatic: true, friction: 1},
  );
  Matter.World.add(world, [initialCeiling]);

  return {
    body: initialCeiling,
    size: [size.width, size.height],
    color: color,
    renderer: <Ceiling />,
  };
};

Ceiling.propTypes = {
  size: array,
  body: object,
  color: string,
};
Hire our Development experts.
import Floor from '../components/Floor';
import Ceiling from '../components/Ceiling';
Floor: Floor(world,'white',{x: width / 2, y: height - 50},{height: 100, width: width}),
Ceiling: Ceiling(world,'white',{x: width / 2, y: 0},{height: 100, width: width}),






In matter.js, by applying isStatic we can make the floor and ceiling a static body that can never change position or angle and is completely fixed. With the help of this, we can now prevent the plane from falling down or going above our game area.

Now, we should make the game more interesting by adding obstacles and increase the difficulty level.

src/components/Obstacle.js

Hire our Development experts.
import React from 'react';
import {View} from 'react-native';
import {array, object, string} from 'prop-types';
import Matter from 'matter-js';

const Obstacle = props => {
  const width = props.size[0];
  const height = props.size[1];
  const x = props.body.position.x - width / 2;
  const y = props.body.position.y - height / 2;
  return (
    <View
      style={[
        {
          position: 'absolute',
          left: x,
          top: y,
          width: width,
          borderRadius: 20,
          height: height,
        },
      ]}
    />
  );
};

export default (world, type, pos, size) => {
  const initialObstacle = Matter.Bodies.rectangle(
    pos.x,
    pos.y,
    size.width,
    size.height,
    {isStatic: true, friction: 1},
  );
  Matter.World.add(world, [initialObstacle]);

  return {
    body: initialObstacle,
    size: [size.width, size.height],
    type: type,
    scored: false,
    renderer: <Obstacle />,
  };
};

Obstacle.propTypes = {
  size: array,
  body: object,
  color: string,
};

src/utils/random.js☟

Hire our Development experts.
export const getRandom = (min, max) => {
  return Math.floor(Math.random() * (max - min + 1) + min);
};

export const topObstacleHeight = getRandom(150, 300);
export const bottomObstacleHeight = getRandom(200, 300);

We will use Math.random for producing different sizes for every obstacle.

src/utils/constants.js

Hire our Development experts.
const Constants = {TOP_PIPE_WIDTH: 250,BOTTOM_PIPE_WIDTH: 100,};
export default Constants;

Update src/entities/index.js

Hire our Development experts.
import Obstacle from '../components/Obstacle';
import {getRandom,topObstacleHeight,topObstacleHeight} from '../utils/random';
import Constants from 'src/utils/constants';
Obstacle1: Obstacle(world,'top',{x: width * 2 - Constants.TOP_PIPE_WIDTH / 2, y: getRandom(100, 400)},{height: topObstacleHeight, width: Constants.TOP_PIPE_WIDTH}),
Obstacle2: Obstacle(world,'bottom',{x: width - Constants.BOTTOM_PIPE_WIDTH / 2,y: getRandom(400, 700)},{height: bottomObstacleHeight, width: Constants.BOTTOM_PIPE_WIDTH}),

But creating obstacles is not enough, we need to move these obstacles and create never-ending obstacles. To achieve this goal we need to use matter.js.

src/systems/obstacle.js

Hire our Development experts.
import Matter from 'matter-js';
import Constants from '../utils/constants';
import {getRandom} from '../utils/random';
import {width} from '../utils/styleSheet';

const UpdateObstacle = (entities, {time, dispatch}) => {
  for (let i = 1; i <= 2; i++) {
    if (
      entities['Obstacle' + i].type === 'top' &&
      entities['Obstacle' + i].body.position.x <=
        -1 * (Constants.TOP_PIPE_WIDTH / 2)
    ) {
      entities['Obstacle' + i].scored = false;
      Matter.Body.setPosition(entities['Obstacle' + i].body, {
        x: width * 2 - Constants.TOP_PIPE_WIDTH / 2,
        y: getRandom(100, 300),
      });
    } else if (
      entities['Obstacle' + i].type === 'bottom' &&
      entities['Obstacle' + i].body.position.x <=
        -1 * (Constants.BOTTOM_PIPE_WIDTH / 2)
    ) {
      entities['Obstacle' + i].scored = false;
      Matter.Body.setPosition(entities['Obstacle' + i].body, {
        x: width * 2 - Constants.BOTTOM_PIPE_WIDTH / 2,
        y: getRandom(300, 500),
      });
    } else {
      Matter.Body.translate(entities['Obstacle' + i].body, {x: -4, y: 0});
    }
  }
  return entities;
};

export default UpdateObstacle;

Update src/systems/index.js :

Hire our Development experts.
import Physics from './physics';
import Plane from './plane';
import Obstacle from './obstacle';
export default [Physics, Plane, Obstacle];

Matter.js has a feature called translate through which we can change the position by a given vector relative to its current position, without imparting any velocity. Due to this, we get an illusion of moving obstacles.

If the x-axis position of an obstacle body becomes negative of its width than it means it has left the screen. At that time we can set the position of that body to 2 times its original position and so on this cycle will repeat, making it a never-ending loop.

Last we want to check when a collision is made so that we can stop the game and announce the score.

Matter.Events.on help to pass a callback function whenever a particular event occurs. We can easily add a collision event with the help of this method.

Update src/systems/.js :

Hire our Development experts.
Matter.Events.on(engine, 'collisionStart', (event) = {
    dispatch({ type: "game-over"});
});
Hire our Development experts.
onEvent = e =>
 {
  if (e.type === 'gameOver') {
   Alert.alert('Game Over');
   this.setState({running: false,});
  }
 };

<GameEngine
 ref={(ref) => { this.gameEngine = ref; }}
 style={styles.gameContainer}
 onEvent={this.onEvent}
 running={this.state.running}
 systems={Systems}
 entities={this.entities}>
</GameEngine>
